EUROCOM Notebook Manual page 93

3. Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.
4. Carefully disconnect the fan cable
9
5. Remove screws -
10
, and remove the cover
8
8
from the hard disk cover.
11
11
10
.
9
8
Upgrading the Hard Disk Drive 6 - 5
Upgrading The Computer
Fan Cable
Make sure you recon-
nect the fan cable
before screwing down
the bay cover.
Figure 6 - 3
Bay Cover Removal
Figure 6 - 4
Hard Disk Assembly
Screws
8
6
