Bios; Storage; Audio; Keyboard, Pointing Device & Buttons - EUROCOM Notebook V10.1.00 User Manual

BIOS

One 32Mb SPI Flash ROM
Phoenix™ BIOS

Storage

One Changeable 12.7mm(h) Super Multi/
Blu-ray Combo Optical Device Drive with
SATA Interface (Factory Option)
One Changeable 2.5" / 9.5 mm (h) HDD
with SATA (Serial) Interface

Audio

High Definition Audio Interface
S/PDIF Digital Output
Built-In Microphone
2 * Built-In Speakers
Keyboard, Pointing Device & Buttons
Isolated A4 Size Keyboard
Built-in Touchpad with Multi-Gesture
Functionality
Three Instant Buttons; WLAN On/Off,
Mute, Camera On/Off
GPU Mode Button

Interface

Four USB 2.0 Ports
OR
Three USB 2.0 Ports and One (Factory
Option) USB 3.0 Port
One eSATA Port
One External Monitor Port
One HDMI Out Port
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF-Out Jack
One RJ-45 LAN Jack
One RJ-11 Modem Jack (Factory Option
for Model A Computers)
One DC-In Jack

Card Reader

Embedded 3-in-1 Card Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC Compatible
- MS/ MS Pro/ MS Duo
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
Specifications

Slots

Two Mini-Card Slots with PCIe (Slot 1) &
USB (Slot 2) interfaces:
Slot 1 for WLAN Module
Slot 2 for 3.75G Module (Factory Option
for Model A Computers)

Communication

56K Fax/Modem V.90 & V.92 Compliant
(Factory Option for Model A
Computers)
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
Intel® WiFi Link 6200 (802.11 a/g/n) Half
Mini-Card PCIe WLAN Module
(Factory Option)
Intel® WiFi Link 6300 (802.11 a/g/n) Half
Mini-Card PCIe WLAN Module
(Factory Option)
3rd Party WLAN 802.11b/g/n Half Mini-
Card Module with PCIe Interface
(Factory Option)
Specifications C - 3
C
