Upgrading The Computer
Figure 6 - 5
6
Removing the
Optical Device
6 - 8 Upgrading the Optical (CD/DVD) Device
5. Remove the screw at point
optical device at point
6. Reverse the process to install the new device.
7. Replace the hard disk bay cover.
Model A
Model B
, and use a screwdriver to carefully push out the
5
.
6
5
6
5
6
Model A
6
Model B
6
