Fingerprint Reader (FPR)

You can add a fingerprint reader to the C-Series touchcomputer to any of the four
mounting locations located on the display head top, bottom, left, and right.
Software application and drivers can be found in the following directory or on
www.elotouch.com
C:\EloTouchSystems\SetupFiles\Peripherals
The fingerprint reader is powered by the USB bus. The reader optically scans the
fingerprint when the user touches the glowing window. Optical technology gives
the highest quality fingerprint scans and reliability.
Fingerprint reader specifications are shown in the table below.
Feature
Fingerprint reader
Power supply
Current draw – scanning mode
Current draw – idle mode
Current draw – suspend mode
Image resolution
Image color
Scan capture size
Image capture speed
USB type
Operating temperature
Electrostatic discharge (ESD)
Part number
Testing the FPR
15. Double-click the Fingerprint Reader Test icon to start the test application.
Specification
DigitalPersona U.are.U
5.0VDC +/- 0.25V
190 mA (typical)
140 mA (typical)
1.5 mA (typical)
512 dpi
8-bit gray level
14.6mm (nominal width) x 18.1mm (nominal
length)
100 ms
1.0, 1.1, or 2.0
0 to 40°C
Up to 15kV mounted in case
E375206
C-Series Touchcomputer for Healthcare Applications User Guide 19
