Customer Display (0700L 7" LCD Monitor)

You can optionally add a customer display to the C-series touchcomputer to the
back of the touchcomputer. Software application and drivers can be found in the
package or on
Note: Requires Rear-facing LCD Monitor Bracket Kit (Part number E835074).
Feature
Display type
Aspect Ratio
Useful Screen Area
Brightness
Colors
Contrast Ratio
Viewing Angle (typical)
Interface
Part Number

Fingerprint Reader (FPR)

You can add a fingerprint reader to the C-series touchcomputer to any of the three
mounting locations located on the display head top, left, and right. Software
application and drivers can be found in the following directory or on
www.elotouch.com
C:\EloTouchSolutions\Peripherals
The fingerprint reader is powered by the USB bus. The reader optically scans the
fingerprint when the user touches the glowing window. Optical technology gives
the highest quality fingerprint scans and reliability.
Fingerprint reader specifications are shown in the table below.
Feature
Fingerprint reader
Power supply
Current draw – scanning mode
www.elotouch.com
Description
7" diagonal, Active matrix TFT LCD
16x9 Widescreen
Horizontal: 6.0" (154mm)
Vertical: 3.4" (87mm)
160-180 nits
16.7 million
500:1
Horizontal: ±70° or 140° total
Vertical: -60°/+50° or 100° total
USB
AccuTouch (E791658); No touch (E807955)
Specification
DigitalPersona U.are.U 4000B
5.0VDC +/- 0.25V
190 mA (typical)
