Elo TouchSystems C-Series User Manual page 27

Feature
Brightness
Image setting
Color
OSD
Language
Recall
Miscellaneous
Exit
OSD and Power Button Control
The OSD menu and power button are enabled by default.
To enable or disable the OSD function:
6. Simultaneously press Menu/Exit and the Left (<-) key for two seconds. A
window appears displaying OSD ENABLE or OSD DISABLE.
7. When the OSD is disabled, the OSD menu is not visible.
Description
Adjust brightness and contrast.

Brightness: Adjusts the backlight of the monitor.

Contrast: Adjusts the maximum luminance level of the monitor.
Adjusts H position, V position, clock, and phase.

H position: Moves the screen horizontally right and left (1 pixel
pitch increment).

V position: Moves the screen vertically up and down (1 line
increment).

Clock: Adjusts the ratio of dividing frequency of the dot clock.

Phase: Adjusts the phase of the dot clock.
Sets color temperature (9300K, 7500K, 6500K, 5500K, or User
Preset).
Adjusts H position, V position, and OSD timeout.

H position: Adjusts the OSD menu screen position left or right.

V position: Adjusts the OSD menu screen position up or down.

Timeout: Adjusts the amount of time that the OSD menu is
displayed.
Changes language to English, French, Italian, German, Spanish,
Japanese, Simplified Chinese, or Traditional Chinese.
Sets color recall and recall defaults. Restores original factory settings.
Adjusts sharpness, enables/disables DDC/CI function.
Exits the OSD.
