To enable or disable the power button (PWR) lock function:
8. Simultaneously press Menu/Exit and the Right (->) key for two seconds. A
window appears displaying PWR ENABLE or PWR DISABLE.
9. When the power button lock feature is activated, the power button is disabled.
L.E.D. Functionality
The C-Series base has a LED indicating the state of the touchcomputer. The table
below shows LED state and corresponding color.
LED Color to Observer
Off
Amber
Amber/Green
Green
State
No input power — Off mode
Input power present – Off mode or hibernation
Input power present — Standby
Input power present — Power On
C-Series Touchcomputer for Healthcare Applications User Guide 13
