13. Slide a card through the MSR and verify that the data is displayed in the
application window.
14. If the card ID appears in the Reader Output window, the reader is functioning.

Customer Display

You can optionally add a customer display to the C-Series touchcomputer to any of
the four mounting locations located on the display head top, bottom, left, and right
of the touchcomputer. Software application and drivers can be found on
www.elotouch.com
Feature
Display type
Display color
Display pattern
Brightness
Characters available
Dot size (X x Y)
Font size
Character number
Interface
Part number
Description
Vacuum fluorescent display
Green
5 x 7 dot matrix
350-600 cd/m
95 alphanumeric & 32 international characters
0.86 x 1.2 mm
5.5(W) x 10.5(H)
20 characters by 2 lines, for a 5 x 7 dot matrix font
USB
E879762
