On-Screen Display (OSD)

OSD Menu

1. To display the OSD Menu, press the Menu button.

Press the RIGHT button or LEFT button to toggle and the SELECT button to

select from the different OSD sub-menus and functions.

2. When the function you want to change is shown, press the SELECT button.

3. To adjust the value of the function:

4. Pressing the RIGHT button increases the value of the selected OSD control

option.

5. Pressing the LEFT button decreases the value of the selected OSD control

option.

The OSD provides the following settings.

Feature

Auto adjust

Description

Automatically adjusts system clock.

C-Series Touchcomputer for Healthcare Applications User Guide 11
