3. If the card ID appears in the Reader Output window, the reader is functioning.

Customer Display

You can optionally add a customer display to the C-Series touchcomputer to any of
the three mounting locations located on the display head top, left, and right of the
touchcomputer. Software application and drivers can be found in the following
directory or on
C:\EloTouchSystems\Peripherals
Feature
Display type
Display color
Display pattern
Brightness
Characters available
Dot size (X x Y)
Font size
Character number
Interface
Part number
www.elotouch.com
Description
Vacuum fluorescent display
Green
5 x 7 dot matrix
350-600 cd/m
95 alphanumeric & 32 international characters
0.86 x 1.2 mm
5.5(W) x 10.5(H)
20 characters by 2 lines, for a 5 x 7 dot matrix font
USB
E879762
