CompatibleComponents
A wide variety of compatible Video Cassette Recorders
(VCR's), camcorders, laser disc players, and audio
components are available. Check with your dealer for
details.
Other brands of components can also be connected to your
TV. Refer to the component's owner's manual tk)r the
manufacturer's recommended hookup instructions.
Stacking Arrangements
If you are connecting several components follow these
general rules when arranging them.
If the components are arranged horizontally, allow at least
an inch or two of space between them so air can circulate
freely. This will also provide some space between the
audio devices to minimize interference.
If components are arranged vertically on shelves, place the
Stereo Amplifier at the top so that heated air rising from it
will not pass around the other components. Leave at least 4
inches of clearance above the amplifier.
Do not block the ventilation holes in the components. If
components are placed on rugs or deep-pile mats, the
ventilation holes in the bottoms may be blocked and
overheating could result.
Some VCR's may cause interference in TV's. When
placing a VCR under your TV, try to keep at least 18
inches between the bottom of the TV and the top of the
VCR. If interference is present when the VCR is used on
top of the TV or at the 18-inch distance below the set,
move the VCR beside the TV. If moving the VCR does
not solve the interfierence problem, try plugging the VCR
into a different wall socket.
Turn Off Power Before ConnectingComponents
Always turn off power to all components before you
connect or disconnect any cables. This will protect your
components fi*om possible electrical surges that could
damage your equipment.
This is a good practice for all your audio and video
components - TV's, VCR's, audio systems, computers, etc.
Plugging in Power Cords
Do not plug any power cord into a wall outlet until you are
finished making connections.
Many components have "convenience outlets" on their
back panels so you can plug power cords from other
components into a "convenience outlet" instead of a wall
outlet. Usually these outlets will be labeled either
"switched" or "unswitched'.
If the outlet is labeled "switched", that means power to the
outlet will be switched off when the component's power
button is switched off,
If the outlet is labeled "unswitched", that means power will
always be available at that outlet, even when the
component is turned off.
Depending on the size of your system, you may prefer to
use an extension cord or a "multiple adapter" to get enough
outlets liar all your components
The power cords on your ProScan components are
"polarized" (one blade is wider than the other). Be sure
the extension cord or multiple adapter is also polarized.
The plug should fit in the outlet only one way.
Position Cables to Avoid Hum
The possibility of picking up hum (interference noise) in
the audio/video cables will be reduced if you keep them
away from the back of the TV. Route the cables to the
sides of the TV's back panel instead of straight down the
middle.
All cable plugs should be firmly seated in the jacks where
they connect to the equipment. If a plug is not connected
firmly, audio hum or smeared video may result.
If your antenna cable is flat twin-lead cable, try to keep it
away t¥om the audio/video cables as much as possible.
Excess flat, twinqead cable should be cut off instead of
coiled behind the TV. Round, coaxial, antenna cable is
usually shielded and can be coiled or placed next to
audio/video cables without causing interference.
PositionSpeakers to Avoid Interference
Placing external speakers with unshiekted magnets too
close to the TV may result in the speaker magnets affecting
the quality of the picture. Such speakers should be located
at least eight inches away.
If unshielded speakers are too close to the TV, colored
streaks will appear along the sides of the picture. If this
happens, turn off the TV for several minutes while moving
the speakers farther away. Then tuna the TV back on.
The ProScan SPK060 speakers are completely shielded
and can be positioned next to the TV without affecting the
picture.
