ProScan PS35652 Owner's Manual page 43

@EXTERNAL SPEAKER TERMINALSpermit direct connection
of auxiliary speakers, Conneetion details are on
pages 52-5.3.
(_) SURROUNDSPEAKER TERMINALSpermit direct connection
of auxiliary speakers for surround-sound effects. Details
are on pages 16-17 and 52-53.
Note: Either 4-ohm or 8-ohm s_akers should be used. 8-ohm
speakers are preferred.
G@
®
INPUT l JACKS provide tk)r direct connection of video
devices (like VCR's, camcorders, and laser disc players)
or compatible home computers and TV games with
video/audio outputs. To see the signals from a device
connected to the INPUT1 jacks, select TV channel 91.
CABLE/ANTENNA CONNECTORS are used when attaching
either a home antenna and/or a cable:FV
system to your
TV. Connection details are on pages 41-45.
-®
SPEAKER SWITCH
This switch lets you turn off TV's internal speakers so
that sound will instead come through speakers connected
tO EXTERNAL SPEAKERS
terminals.
Details about connecting speakers to the "IV are on
pages 52-53.
Important:
Always place switch in INTERNAL positkm if no
external speakers are used (or if external speakers are e',er
disconnected).
@
INPUT2 JACKS provide
for direct connection of video
devices (like VCR' s, camcorders, and laser disc players)
or compatible home computers and TV games with
video/audio outputs. To see the signals from a device
connected
to the INPUT2jacks,
select TV channel 92.
S-VIDEO CONNECTOR provides for direct S-VHS vide()
connection from ,%VHS VCR or camcorder. Remember
to also connect the S-VItS VCR's or camcorder's audio
jack(s)
to the TV's fNPUT"f LEFTand/or R/MONOaudio
jacks. This is necessary because S-Video cables only
carry the super video (picture), not the audio signal.
Connection details are on pages 47 and 48-49.
To see the signals from a device connected to the S-V'fOEO
jacks, select TV channel 90.
HI-FI OUTAUDIOJACKS feed volume-controlled stereo
audio out fi'om whatever is displayed on the TV screen.
Allows connection of audio amplifier so you can adjust
sound level with TV's remote. Connection derails are
on page 50,
at;:a high
brightness
or eomraSt _tting; the
imzg¢
can N _'_mantmt!y
imprinted the Screen _ese tY_ 0f imprints _¢ _61 _overed bY
your wan'anty _Cause the_ are _;heresult of mistlSel
