NOTE
NOTE
Operating the Jukebox
Setting the SCSI IDs
5. Press
to change the setting and then press
NEXT
and then TURNED OFF or TURNED ON display briefly. Then SCSI ID'S
displays.
You may now view the SCSI ID and LUN numbers using VIEW ID'S, or set a
new SCSI ID number using SET ID'S. (See the following two sections.)

Viewing the Current SCSI IDs

READY > ADMIN * > SCSI ID'S * > VIEW ID'S * >
If you are unfamiliar with basic SCSI addressing or LUN addressing, refer to
Appendix B. A web site is also available for more extensive information at
www.hp.com/isgsupport/optical/index.html
Start with READY in the display.
1. Press
until ADMIN * displays, and then press
NEXT
2. Enter the administration password.
Instructions for entering this password are in "Entering the Administration
Menu Password" previously in this chapter.
3. Press
until SCSI ID'S displays, and then press
NEXT
4. VIEW ID'S displays. Press
5. JKBX ID # LUN # or DRV # ID # LUN # displays. (JKBX ID # stands
for the current ID of the jukebox controller, DRV # ID # is the current ID
setting of the displayed drive number, and "LUN #" is the current logical unit
number.)
Press
or
NEXT
PREV
Tables in Appendix B show the default SCSI IDs and LUNs when LUN mode is
turned on.
6. Press
twice to exit VIEW ID'S.
CANCEL
3-16
.
ENTER
to scroll through the current SCSI IDs and LUNs.
. WAIT FOR UPDATE
ENTER
.
ENTER
.
ENTER
Chapter 3
