The numbers below correspond to the numbers in Figure 1-1 on the previous page:
1
Control panel
2
Mailslot
3
Power switch
4
Right service
access panel
Chapter 1
Identifying Controls and Features
Used to manually control and monitor operation of
the jukebox. A full description of the controls and
indicators on the control panel are in Chapter 3.
Used to load and eject optical disks.
Used to power the jukebox on and off.
A service panel that should be removed only by your
service representative.
Setting Up the Jukebox
1-5
