The numbers below refer to the numbers in Figure 3-1 on the previous page.
1
2
3
4
5
6
NOTE
Figure 3-2 shows the jukebox menus available using the control panel selection
buttons.
Chapter 3
Swivel feature The control panel assembly may be rotated to face the
display (#3 below) toward the front or right side of the
jukebox. The front has the vertical window, the right
side has the mailslot.
Activity light Lit differently to indicate the following:
• Steady Green - power is on
• Flashing Green - an optical drive is being accessed
• Amber - a fault occurred
16-character Displays information about the current operation.
display
Selection Pressed to perform the following operations:
buttons
CANCEL
PREV
NEXT
ENTER
Power switch Used to power the jukebox on and off.
Mailslot Used to load and eject optical disks
Operating the Control Panel
cancels the current operation or choice
scrolls the display choice backward by one
scrolls the display choice forward by one
selects the displayed choice
Operating the Jukebox
3-5
