Initial Margin Shift Setting

Set the initial margin shift value with this program.
When the "INITIAL MARGIN SHIFT SETTING" key is pressed, the
following display will appear.

Erase Width Adjustment

Set the initial setting of the amount of the erase area with this program.
When the "ERASE WIDTH ADJUSTMENT" key is pressed, the
following display will appear.
KEY OPERATOR PROGRAMS
KEY OPERATOR PROGRAMS
INITIAL MARGIN SHIFT
SETTING
SET THE INITIAL MARGIN SHIFT.
SIDE 1
10
1. Adjust the value for each side using the
keys.
q The value can be set from 0mm to 20mm in 1mm increments (0"
to 1" in 1/8" increments).
2. Press the "OK" key.
KEY OPERATOR PROGRAMS
ERASE WIDTH ADJUSTMENT
SET THE INITIAL ERASE WIDTH.
EDGE ERASE
10
1. Adjust the values for the edge erase and the centre
erase respectively using the
q
The values can be set from 0mm to 20mm in 1mm increments
(0" to 1" in 1/8" increments).
2. Press the "OK" key.
OK OK
SIDE 2
(0~20) (0~20)
10
mm mm
OK
CENTRE ERASE
(0~20) (0~20)
10
mm mm
and
and
keys.
8-11
