When adding new switches, avoid fabric segmentation. For more information, see
"Fabric segmentation

Cascaded fabric expansion

Expand a cascaded fabric by connecting a new switch to an available port on an existing switch. If
no ports are available, remove devices from an existing switch, connect the new switch to those ports,
and then reconnect the devices to the new switch.

Meshed fabric expansion

Expand a meshed fabric by connecting a new switch to available ports on an existing switch. If no
ports are available, remove devices from an existing switch, connect the new switch to those ports,
and then reconnect the devices to the new switch. Ensure that multiple paths (ISLs) connect the new
switch to the meshed fabric.

Ring fabric expansion

Expand a ring fabric by adding a switch to the ring.
Add new switches cascaded off the ring, up to the maximum number of switches supported in a single
fabric. When expanding outside the ring, ensure that communicating devices are connected by no
more than seven hops.

Core-edge fabric expansion

Expand a core-edge SAN fabric by adding edge switches. Connect edge switches to available ports
on the backbone switches.
If the current SAN contains only one core switch, add another. Connect edge switches to ports on
the new core switch.

SAN fabric merging

You can merge independent fabrics into a single, larger fabric. Merging enables you to:
Provide more resources to independent SAN fabrics.
Share the resources in two or more fabrics.
Make information in one SAN available to servers in another SAN.
Connect geographically dispersed fabrics into a single SAN.
During initial login, the discovery process determines whether the fabrics are compatible. If not,
segmentation occurs and they continue to operate as separate fabrics (see
"Fabric segmentation
When fabrics merge, the zone configuration databases are updated to include the zone configurations
of each fabric. If a nonzoned fabric merges with a zoned fabric, all zoning information is proliferated
to the nonzoned fabric switches. A zone configuration that is enabled at the time of the merge is also
enabled on the nonzoned fabric switches. Devices in the nonzoned fabric are not accessible until
you add them to the current configuration.
errors" on page 426.
errors" on page 426).
SAN Design Reference Guide 425
