Feature
FCIP-supported operating systems
Documentation

1606 Extension SAN Switch configuration examples

When connecting fabrics through IP, the 1606 Extension SAN Switch serves as an FCIP gateway
with Fibre Channel routing. 1606 Extension SAN Switches that communicate over FCIP links can be
installed in multiple pairs for high availability
Fabric A1
Fabric B1
Figure 105 NSPOF configuration with 1606 Extension SAN Switches providing Fibre Channel routing
and FCIP
.
Figure 106 Fibre Channel routing and FCIP using two 1606 Extension SAN Switches
.
HP supports FCIP configurations in which the 1606 Extension SAN Switch serves as an FCIP gateway
and a Fibre Channel switch. Servers and storage systems that support Continuous Access with FCIP
can be directly connected to the Fibre Channel ports on the 1606 Extension SAN Switch
314 SAN extension
For Continuous Access EVA, see the HP StorageWorks Enterprise Virtual Array compatibility
reference matrix at
conaccesseva/index.html.
For information about the 1606 Extension SAN Switch and DC Dir Switch MP Extension
Blade, see the SAN Infrastructure website:
frastructure/index.html.
1606 Extension
SAN Switch
FCIP with FC routing
1606 Extension
SAN Switch
FCIP with FC routing
Fabric A1
1606 Extension
SAN Switch
Fabric B1
FCIP with FC routing
Requirements
http://h18006.www1.hp.com/products/storage/software/
http://h18006.www1.hp.com/storage/sanin-
(Figure 105) or as a single pair
1606 Extension
SAN Switch
IP A
1606 Extension
SAN Switch
IP B
1606 Extension
SAN Switch
IP A
IP B
(Figure 106).
Fabric A2
Fabric B2
26583b
Fabric A2
Fabric B2
26584a
(Figure 107).
