Third-party QoS and data encryption FCIP products

Third-party vendors provide two classes of FCIP solutions that complement hardware: QoS devices
and IP data encryption devices. Detailed information about these products is available at the vendor
websites.

FCIP QoS products

You may need additional hardware to improve the QoS for an existing IP network. This hardware lets you use
the existing network with an FCIP gateway.
Table 146 FCIP QoS products
Vendor name/website
Allot Communications, Inc.
http://www.allot.com
Packeteer, Inc.
http://www.packeteer.com
Riverstone Networks, Inc.
http://www.riverstonenet.com

Fibre Channel over SONET

You can connect local SANs with a SONET to create an extended SAN.
An FC-SONET gateway resides at the end of an inter-site link. Each FC-SONET gateway encapsulates
Fibre Channel frames into SONET packets before transmitting the frames over the network. Upon
receiving the packets, another FC-SONET gateway extracts the original Fibre Channel frames from
the SONET packets and retransmits them to the destination Fibre Channel node.
The FC-SONET gateway also handles SONET-level error recovery.
This section describes the following topics:
FC-SONET IP link
FC-SONET network
Third-party SONET

FC-SONET IP link configurations

Using FC-SONET, you can configure the SANs through a single link, dual links, or shared ISL links.
FC-SONET dual-link configuration
A dual-link configuration is the benchmark for disaster protection
other link temporarily handles all data replication. For enhanced fault tolerance, you use two IP
providers, accessing the data center through two links.
296 SAN extension
Table 146 lists QoS hardware you can use with FCIP gateways.
Device
NetEnforcer
PacketShaper6500
RS3000, RS8000
configurations, page 296
considerations, page 297
gateways, page 297
Purpose
Application traffic and band-
width management system
MPLS GbE routers
(Figure 86). If one link fails, the
Support
Continuous Access EVA
