Table 174 XP Continuous Access ATM and SONET/SDH products
XP storage
Configuration
system
ESCON (ATM) XP24000
XP20000
ESCON (ATM) XP12000
XP10000
Fibre Channel XP512
XP48
Fibre Channel XP12000
XP10000
XP1024
XP128
XP512
XP48
Fibre Channel For a list of sup-
ported storage
systems, contact
your HP repres-
entative.
nl
OC-3—Brocade-McDATA-CNT Ultranet Storage Director (USD) firmware 2.7 or 3.2.1
OC-3—Brocade-McDATA-CNT-Inrange 9801 SNS firmware 2.3 (Build 27) or 2.4 (Build 13)
Brocade-McDATA-CNT-Inrange 9811H FW ACP-3; 3.1.1702
Requirements:
Buffer size = 64 credits/port
1 x ATM OC-3 (155 Mb/s) port
Interoperability mode = 1
E_D_TOV = 5,000
Note: This converter has been discontinued. There is limited support for existing installations.
OC-3—Brocade-McDATA-CNT Edge 1003 with B-series switches
OC-12—Brocade-McDATA-CNT Edge 1002 with B-series switches
Requirements:
With Brocade-McDATA-CNT Edge firmware 1.5.1 and B-series switches, ISL R_RDY mode
= ON must be set on the E_Port of the switch (portcfgISLMode = 1).
A remote switch license is required for B-series switches using firmware 2.x.
E_D_TOV = 5,000
R_A_TOV = 10,000
DataFieldSize = 2,048
OC-3—Brocade-McDATA-CNT (Inrange) 9801H or L, 2.3 (Build 28) or 2.4 (Build 13)
Requirements:
Buffer size = 64 credits/port
1 x ATM OC-3 (155 Mb/s) port
Interoperability mode = 1
E_D_TOV = 5,000
Note: This converter has been discontinued. There is limited support for existing installations.
Cisco FCMR-4 (800-22030-03) for FC over SONET/SDH
Requirements:
Firmware 57-5391-03, hardware revision 03
FC/FICON (1 Gb/s or 2 Gb/s) over SONET/SDH (OC-3,OC-12, OC-48, or OC-192)
255 buffer credits (ingress) and 1,200 buffer credits (egress)
ML-Series, CE-Series, G-Series, or E-Series
1
Supported bandwidths and products
