A System Power - Intergraph InterServe 8000 Setup Manual

A System Power

This appendix provides information about the system's rated power consumption (load). If
using an external power source, such as an AC distribution box or uninterrupible power
supply (UPS), refer to the documentation delivered with the power source for information
about its capabilities.
The following table shows the system's rated power information.
Voltage
(Vac)
90
100
120
220
240
254
The rated power load of external options (tape libraries, disk arrays, and so on) is printed on
the back of the device. Add the load for the system plus each device to determine if the
external power source can handle the load. If it cannot, add an additional power source.
The power load of a device is the product of its operating Voltage (such as 110 Vac) times its
current (such as 3 Amps).
Frequency Rated Current
(Hz) (Amps)
60 10
60 10
60 10
60 5
60 5
60 5
Rated Load
(VA)
900
1000
1200
1100
1200
1270
111
