Connecting the Cables

All cable ports on the base unit and other Intergraph equipment are keyed or molded and
clearly labeled to ensure proper cable attachment. If a cable is not attaching easily, ensure
that you are aligning the cable connector correctly with the port.
The following figure shows the back of the base unit.
I/O Connector
I/O Expansion
Power Supplies
Panel
Panel
