Controls Description - Furuno FELCOM 16 Operator's Manual

1.2.2

Controls description

The FELCOM 16 is almost 100% keyboard controlled. Operation is carried out
with the function keys, numbered F1-F10 at the top of the terminal unit's
keyboard.
Controls
Esc
F1-F10
Backspace
Insert
Delete
Home
End
PgUp
PgDn
[↑], [↓], [←], [→] Control the cursor.
Enter
Shift
Alt
Space Bar
Caps Lock
Tab
Cancels key input and returns to previous display screen.
These are the function keys. They choose menus.
Deletes the character to the left of the cursor.
Works the same as "paste." See "Copying and pasting text" in
paragraph 3.2.4.
Deletes the character selected with the cursor.
Moves the cursor to the top of the message being edited.
Moves the cursor to the bottom of the message being edited.
Goes to the previous page of the edit screen.
Goes to the next page of the edit screen.
Registers key input.
Chooses upper or lower case alphabet. Press and hold down
the key and then press the [Caps Lock] to get upper or lower
case alphabet. Note that only upper case alphabet are used in
telex.
Executes the shortcut key operation when combined with an
alphabet key. See paragraph 1.2.3.
Inserts a space. In addition, it displays the file list, a partial
view of a file, etc., depending on menu.
Turns upper case alphabet input on or off. The Caps Lock LED
lights when upper case input is on.
Inserts horizontal tab characters. The number of tab characters
the key can insert per line of text can be programmed for two,
four or eight tabs.
1. OPERATIONAL OVERVIEW
1-3
