Furuno Felcom 16 Installation Manual

Furuno Felcom 16 Installation Manual

Inmarsat mini-c mobile earth station
Hide thumbs Also See for Felcom 16:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
INMARSAT MINI-C MOBILE EARTH STATION

TABLE OF CONTENTS

EQUIPMENT LISTS.....................................................................................................................iii
SYSTEM CONFIGURATION .......................................................................................................iv
1.
MOUNTING THE UNIT..........................................................................................................1
1.1
Antenna Unit.................................................................................................................1
1.2
Communication Unit .....................................................................................................7
1.3
AC/DC Power Supply Unit PR-240 (option) .................................................................7
2.
WIRING .................................................................................................................................8
2.1
Antenna Cable Connector at the Terminal Unit............................................................9
3.
SETTINGS AFTER THE INSTALLATION ..........................................................................11
3.1
Installing software.......................................................................................................11
3.2
Setting the IMN (Inmarsat Mobile No.) .......................................................................15
4.
CHANGING POWER SUPPLY SPECIFICATIONS ............................................................16
PACKING LISTS....................................................................................................................... A-1
OUTLINE DRAWINGS.............................................................................................................. D-1
INTERCONNECTION DIAGRAM ............................................................................................. S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
www.furuno.co.jp
FELCOM 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Felcom 16 and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno Felcom 16

Summary of Contents for Furuno Felcom 16

  • Page 1: Table Of Contents

    INMARSAT MINI-C MOBILE EARTH STATION FELCOM 16 Installation Manual TABLE OF CONTENTS EQUIPMENT LISTS........................iii SYSTEM CONFIGURATION .......................iv MOUNTING THE UNIT......................1 Antenna Unit.........................1 Communication Unit .....................7 AC/DC Power Supply Unit PR-240 (option) ..............7 WIRING ..........................8 Antenna Cable Connector at the Terminal Unit............9 SETTINGS AFTER THE INSTALLATION ................11...
  • Page 4 SAFETY INSTRUCTIONS CAUTION WARNING Do not open the equipment Confirm that the power supply voltage unless totally familiar with is compatible with the voltage rating electrical circuits and of the equipment. service manual. Connection to the wrong power supply Only qualified personnel can cause fire or equipment damage.

  • Page 5: Equipment Lists

    EQUIPMENT LISTS Standard Supply Name Type Code No. Remarks Antenna Unit IC-116 Communication Unit IC-216 Junction Box* IC-315 w/CP16-02501 SSAS Alert Unit* IC-307 w/CP16-03101, FP16-00901 CP16-02101 004-439-060 For 15/30 m antenna cable** CP16-02111 004-439-070 1 set For 50 m antenna cable** CP16-02121 004-439-080 For 100 m antenna cable**...

  • Page 6: System Configuration

    POWER SUPPLY 100-115/200-230 AC-DC PRINTER 1φ, 50/60 Hz Power Supply PR-240 POWER SUPPLY PERSONAL 12-24 VDC FURUNO INMARSAT MINI-C MOBILE EARTH STATION COMPUTER POWER (PC/AT compatible) COMMUNICATION UNIT IC-216 (with internal GPS receiver) : Standard JUNCTION BOX IC-315 : Option...
  • Page 7 This page is intentionally left blank.

  • Page 8: Mounting The Unit

    1. MOUNTING THE UNIT NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Antenna Unit Mounting Location •...
  • Page 9 340 mm, which also is the length of the supplied ground wire. Note: Use of the mounting pipe (FURUNO supply or the equivalent) is mandatory in case of FFA version. See the equipment list at the beginning of this manual for information.
  • Page 10 1. MOUNTING THE UNIT For 15 or 30 m cable 1. Apply silicone sealant (local supply) to the threads of the pipe. 2. Unscrew three screws to remove the antenna base from the antenna unit. 3. Pass the antenna cable through the pipe, antenna base in order. 4.
  • Page 11 1. MOUNTING THE UNIT 10. Wrap self-bonding tape around the connection of antenna base and pipe, and then wind vinyl tape over self-bonding tape. 11. Remount the antenna unit (upper) on the antenna base. (Torque: 2.6 N·m ± 10%) 12. Fix the ground wire RW-4747 (supplied) between the ground terminal on the antenna unit and the ship’s ground point.
  • Page 12 1. MOUNTING THE UNIT For 50 or 100 m cable 1. Apply silicone sealant (local supply) to the threads of the pipe. 2. Unscrew three screws to remove the antenna base from the antenna unit. 3. Pass the cable assy TPA5FB0.3NJ5FBA-5DFB (supplied, 300 mm) through the shrink tube (SCM2, supplied).
  • Page 13 1. MOUNTING THE UNIT 12. Fix the ground wire RW-4747 (supplied) between the ground terminal on the antenna unit and the ground stud on the mast. 13. Connect the antenna cable (50 or 100 m) and cable assy (attached at step 4). 14.

  • Page 14: Communication Unit

    1. MOUNTING THE UNIT Communication Unit Mounting Select the following place to mount the communication unit. • Provide sufficient ventilation. • For maintenance and checking purpose, leave sufficient space at the sides and rear of the unit. Use two tapping screws (4x40, supplied) to fix the communication unit. You can insert screws from the top and bottom side of the communication unit for bulkhead mounting.

  • Page 15: Wiring

    TNCP-NJ Use of wrong fuse can result in damage to the equipment. Connector N-P-12DSFA N-P-8DFB (supplied, local arrange) 17JE-573-10 (5 m, option) FM-C3FPS-002-035, 3.5 m Copper strap 1.2 m Power supply 12-24 VDC Wiring of FELCOM 16...

  • Page 16: Antenna Cable Connector At The Terminal Unit

    2. WIRING Antenna Cable Connector at the Terminal Unit 8D-FB-CV (50 m) Outer Sheath Dimensions in millimeters. Shield Remove outer sheath and armor by the Armor Inner Sheath dimensions shown left. Expose inner sheath and shield by the dimensions shown left. Cover with heat-shrink tubing and heat.
  • Page 17 2. WIRING 12D-SFA-CV (100) Dimensions in millimeters. Outer Sheath Armor Shield Inner Sheath Remove outer sheath and armor by the dimensions shown left. Expose inner sheath and shield by the dimensions shown left. Twist shield end. Slip on clamp nut, gasket and clamp as shown left. Clamp Gasket Washer...

  • Page 18: Settings After The Installation

    3. SETTINGS AFTER THE INSTALLATION Installing software After installing the equipment, install the FELCOM 16 software (F16PC) in the PC as follows: 1. Turn on the PC. 2. Set FD-ROM in floppy disk drive. 3. Click the icon of “SETUP.EXE” in the floppy disk. The setup procedure begins, showing the welcome dialog box.
  • Page 19 3. SETTINGS AFTER THE INSTALLATION 4. Click the [Next] button. Choose destination location dialog box 5. Click the [Next] button. Select program folder dialog box...
  • Page 20 3. SETTINGS AFTER THE INSTALLATION 6. Click the [Next] button. Start copying files dialog box 7. Click the [Next] button and the installation begins. When the installation is completed, the FELCOM 16 dialog box appears. FELCOM 16 dialog box...
  • Page 21 Note: If you want to launch the program file now check the box next to “Yes, Launch the program file.” The application will launch after the completion of step 9. 9. Click the [Finish] button. The FELCOM 16 PC application shortcut is created on the desktop.

  • Page 22: Setting The Imn (Inmarsat Mobile No.)

    To clear the IMN, press [I] [M] [N] in order while pressing the [Alt] key down at step 6. When using the FELCOM 16 for VMS (Vessel Monitoring System), DNID (Data Network ID) has to be downloaded via the LES (Land Earth Station). This arrangement is normally done...

  • Page 23: Changing Power Supply Specifications

    4. CHANGING POWER SUPPLY SPECIFICATIONS The AC/DC power supply unit PR-240 is shipped ready for connection to a 200-230 VAC ship’s mains. If the ship’s mains is 100 VAC-115 VAC, change the tap connection and terminal board connection as below. Attach a label supplied as accessories to the front panel according to the ship’s mains.
  • Page 33 Dec.19'05...
  • Page 36 Y. Hatai...
  • Page 40 The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN Telephone : +81-(0)798-65-2111 : +81-(0)798-65-4200 A : MAR 2003 All rights reserved. Printed in Japan D7 : MAR . 23, 2009 Pub. No. IME-56380-D7...
