Parts List

This equipment contains complex modules in which fault diagnosis and repair down to
component level are not practical (IMO A.694(17)/8.3.1. Only some discrete components
are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value
for shipboard maintenance; therefore, they are not listed in the manual. Major modules can
be located on the parts location photos on the next several pages.
FURUNO
PARTS LIST
SYMBOL TYPE
COMMUNICATION UNIT IC-216
PRINTED CIRCUIT BOARD
16P0208B, RF CON/CPU
16P0217, PWR
16P0227, PWR C
ASSEMBLY
GN 8097, GN 80 (option)
ANTENNA UNIT IC-116
PRINTED CIRCUIT BOARD
ANTENNA CASE
(ANT RF BOARD (16P0216))
ANTENNA BASE
ANTENNA ELEMENT
(ANT-B BOARD (16P0206))
REMARKS
APPENDIX
AP-21
