APPENDIX
Parts Location
Communication unit
PWR C Board
(16P0227)
PWR Board
(16P0217)
Communication unit, cover opened, INT GPS assy. installed
Antenna unit
Antenna Case
AP-22
ANT RF Board
(16P0216)
Antenna Element
Antenna unit, cover opened
RF CON/CPU
Board
(16P0208 B)
INT GPS Assy.
(GN809 7)
ANT B Board
(16P0206)
