The Hard Disk Drive

The hard disk drive is used to store your data in the computer. The Primary
hard disk is mounted in a removable case and can be taken out to accommo-
date other 2.5" IDE hard disk drives with a height of 9.5 mm. You may have
a second, and third hard disk depending on the configuration purchased (see
"Jumper Settings for Multiple Hard Disk Use" on page 1 -
The Primary hard disk
1
der the battery, as seen below. Further details on removing and inserting the
hard disk are available in
Depending on the configuration purchased your hard disks may be configured
as a RAID (see "RAID Configuration" on page 7 -
is accessible from the bottom of your computer un-
"Upgrading the Primary Hard Disk" on page 6 -
16).
7.
23).
1
Hard Disk
The Hard Disk Drive 2 - 11
Using The Computer
Power Safety
Before attempting to
access any of the inter-
nal components of
your computer make
sure that the AC power
is not connected, and
that the machine is
turned off. Also ensure
that all peripheral ca-
bles, including phone
lines, are disconnected
from the computer.
Figure 2 - 7
Primary Hard Disk
Location
2
