Introduction
1
Drive Warning
Don't try to remove the
hard disk (HDD) while
the system is on. This
could cause data loss
or damage.
Unauthorized removal
or tampering with the
HDD may violate your
warranty. If you are in
doubt,
consult
service representative.
1 - 16 Left Side View
Hard Disk Drive
The hard disk drive is used to store your data. You can have up to three hard
disks in your computer depending on the configuration options purchased.
You may have one primary HDD, one optional HDD in the 1st modular
drive bay (Bay One), and one optional HDD in the 3rd modular drive bay
(Bay Three). See information on pages
on upgrading/replacing your hard disk drive. Your hard disks may be arranged
in a RAID configuration depending on the configuration purchased.
your
If you are using more than one hard disk in your computer, make sure to set the
jumpers on all your hard disks to the cable select option in order for the system to
recognize all the disks (see your hard disk manual or the information printed on the
hard disk itself for details on the jumper settings).
RAID
If you have included a RAID (Redundant Array of Independent Disks) con-
figuration in your purchase option, this will allow you to use your hard disks
in combination for fault tolerance and performance (see
tion" on page 7 -
6 -
Jumper Settings for Multiple Hard Disk Use
23).
7,
6 -
10, &
6 - 10
for information
"RAID Configura-
