EUROCOM D800P Dream Machine User Manual page 149

15. Reconnect the keyboard ribbon cable and carefully tighten the locking collar,
insuring that the cable will not come free.
16. Replace the keyboard by insuring the five tabs at the base of the keyboard
fit into place (you will find these under the Fn, Spacebar (2), arrow and Enter
keys - see Figure 6 -
17. Carefully press the front of the keyboard down so that the two latches at the
front of the keyboard lock down again.
18. Restart the computer.
19. During the startup process, the BIOS will register the new memory
configuration.
14).
Keyboard Tabs
Upgrading The Computer
Upgrading the System Memory 6 - 19
Figure 6 - 14
Keyboard Tabs
6
