Video Driver Controls

The video interface lets you change the screen resolution and color output to
whatever is most comfortable/efficient for you. This is a matter of hardware,
video memory and the driver for your operating system. The driver interface
shows the available options (see
tions).
You can switch display devices from the Display Properties control panel in
Windows as long as the video driver is installed (see
page 4 - 2).

Making Adjustments for the Display

The higher the resolution you set the LCD for, the more information the LCD
can display on screen. To change the LCD's resolution and color depth go to
the Display Properties control panel:
1. Click Start, point to Settings and click Control Panel (if you are in Cate-
gory View choose Appearance and Themes).
2. Double-click Display (icon).
3. In the Display Properties dialog box, click Settings (tab).
4. In Screen area/resolution, move the slider to the preferred setting for
resolution (see in
1
5. In Colors/Color quality, click the arrow and scroll to the preferred setting
for color depth (see
"Display" on page A - 2
Figure 3 - 2 on page 3 -
in Figure 3 - 2 on page 3 -
2
for the LCD op-
"What to Install" on
4).
4).
Video Driver Controls 3 - 3
Advanced Controls
Screen Resolution/
Screen Area Note
You may set the reso-
lution to a higher set-
ting than the panel
supports, however this
will require you to pan
(scroll) around the
screen as the display
area will be larger than
what you can see on
the LCD.
