Left Side View; S/Pdif Out Port / Microphone-In Jack - EUROCOM D270ES VIPER User Manual

Introduction
1
Figure 1 - 4
Front View
1. S/PDIF Out Port /
Microphone-In Jack
2. Headphone-Out
Jack
3. Volume Control
Knob
4. PC Card Slot
5. Infrared
Transceiver
6. 3.5" FDD
7. Y-cable for S/PDIF
Out/Microphone-In

1 - 12 Left Side View

Left Side View
3
1 2
4

S/PDIF Out Port / Microphone-In Jack

You can use this port for S/PDIF (Sony/Philips Digital Interface Format)
output, and to record on your notebook computer with an external micro-
phone. The S/PDIF Out Port allows you to connect your DVD-capable PC
to a Dolby AC-3 compatible receiver for "5.1" or 'dts' surround sound.
You must use the Y-cable provided to enable these functions (S/PDIF
connection is to the longer end of the cable).
