EUROCOM D270ES VIPER User Manual page 126

5. Gently pull the two release latches (
of the memory socket toward the sides of the computer.
6. The module will pop-up, and you can remove it.
3
7. Repeat the process for the second module if necessary.
8. Insert a new module holding it at about a 30° angle and fit the connectors
firmly into the memory slot.
9. The module will only fit one way as defined by its pin alignment. Make sure
the module is seated as far into the slot as it will go. DO NOT FORCE IT; it
should fit without much pressure.
Figure 6 -
& in
1 2
2
1
3
Upgrading the System Memory (RAM) 6 - 7
Upgrading The Computer
4)
on the sides
Contact Warning
Be careful not to touch
the metal pins on the
module's
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's
mance.
Figure 6 - 4
Installing a RAM
Module (part I)
connecting
perfor-
Removing/
6
