Basic Telephone and Modem Interface
DESCRIPTION
CONSIDERATIONS
The Basic Telephone and Modem Interface (BTMI) allows you to connect
most types of telephone and data devices to your MERLIN Plus system,
including auto-dial modems, facsimile machines, credit phones, and answering
telephones.
FIGURE 5-3 The Basic Telephone and Modem Interface
FIGURE 5-4 A basic telephone connected to a BTMI
The BTMI works with Touch-Tone and rotary telephones.
