Manually Signaling a Co-worker

Manually signaling enables you to "buzz" a co-worker at any time—even while you
are on the phone with someone else. The buzz (a beep) sounds at the co-worker's
phone even if s/he is on the phone.
To program a Signal button:
Action
1. Label a button "Signal... "
(include the person's name or
intercom number).
2. Slide the T/P switch to P.
3. Touch the button you Iabelled.
4. Touch * and then 6.
5. Enter the intercom number. For
example, if you want to signal
intercom 12, you would touch:
* 6 1 2
6. Slide the T/P switch to the center
position.
Note: You can program a Signal button or an Auto Intercom button, but not both for
the same person.
To "buzz" a co-worker (don't lift the handset):
Action
Touch the Signal button you
programmed.
48
Result
Signal Mary
You'll hear a ringing pattern. The
red line light(s) come on and the
green line light(s) flash.
Result
The person will hear a beep
through the Speaker.
