System Programming
What You See
Extension :
X X X X
Assign lines/trunks
Lines 01-20 Entry Mode
Lines 21-40
Lines 41-60
Lines 61-80
Exit
Your choice is highlighted.
4-6
Programming Instructions
What You Do...
6. Check red and green LEDs next to
each line button for feature status:
Green LED off or no Ietter on
SPM screen = Iine/trunk or
pool is not assigned to data
station
Green LED on or letter "G"
on SPM screen = line/trunk
or pool is assigned to data
station
Hybrid/PBX only:
Red LED on or letter "R" on
SPM screen = trunk
assigned to a pool
To assign line/trunk to a line button
To remove line/trunk from line button
To assign Pool button
To remove Pool button
PC
Console
Press line Press function
buttons for key for each
each line/trunk line/trunk to
to turn on green make letter "G"
LED appear on
screen
Press function
Press line
button for each key for each
line/trunk to
line/trunk to turn
off green LED erase letter "G"
Press line Press function
button for any key for any one
one of trunks in of trunks in pool
pool to turn on to make both
green LED (red letter "G"
LED remains appear on
on) screen (letter
"R" remains on
screen)
Press line Press function
button for any key for any one
of trunks in pool
one of trunks in
pool to turn off to erase letter
green LED (red "G" (letter "R"
LED remains remains on
on) screen)
