AT&T MERLIN LEGEND Data Manual page 113

Making and Receiving Data Calls
Making Data Calls Through a Modem Pool
5-4
Calling with Analog Data Equipment
To Call an MLX Telephone from Analog Data-Only Stations and Analog
Data Stations Connected via MFM:
In Hybrid/PBX mode, a System Access (SA) button is automatically selected
when you type the modem command to get dial tone (for example, atdt ). You
must dial a dial-out code before the telephone number. In Key or Behind Switch
mode, an Intercom button is automatically selected when you type the modem
command to get dial tone. You can select an outside line assigned to your data
station by dialing the line selection dial-out code (9).
Note: Activate the Privacy feature on each outside call to ensure that the data
call is not interrupted by another user.
Enter modem commands and dial the number using the data terminal keyboard:
1. Put your modem into the data state using the instructions provided with your
modem and communications software.
Type the appropriate modem command, activate Privacy (#31), and dial the
2.
outside telephone number including the dial-out code. You can also use a
Speed Dial code to dial the number.
Note: To enter an account code, dial #82, the account code, and # before
you dial the dial-out code and telephone number.
For example, when using a Hayes-type modem to make an outside call to
another analog data station at telephone number 555-1234 with an account
code of 12345 and a dial-out code of 9:
Type atdt#31#8212345#9,5551234# (comma represents a pause
symbol).
Press Enter.
3. Use the instructions supplied with your modem or data communications
software to send data, receive data, and disconnect the call.
You can make the following types of data calls through an analog-to-digital
modem pool:
inside calls to digital data stations including
calls to a local host computer
calls to a workstation on a local area network (LAN)
outside calls to digital data stations using a Primary Rate Interface (PRI)
digital line/trunk or pool (Hybrid/PBX only)
Calls through a modem pool are placed using two-stage dialing. In the first
stage you dial the extension for the data hunt group for the analog-to-digital
modem pool, and in the second stage you dial the extension or telephone
number of the digital data station you are calling. The second stage of the call
is automatically private.
