Making and Receiving Data Calls
See "System Data Features," "Account
Code Entry," and "System Speed Dial" in
this chapter.
Answering Data Calls
See the instructions supplied with your
modem.
5-6
Calling with Analog Data Equipment
To Call an MLX Telephone from Analog Data-Only Stations and Analog
Data Stations Connected via MFM:
1. Use the instructions provided with your modem and the communications
software to put the modem in the data mode.
2. Type the appropriate modem command and the extension number for the
data hunt group for the analog-to-digital modem you are using. For example,
when using a Hayes-type modem to make a data call to a digital data station
using the analog-to-digital modem pool at extension 775
Type atdt775.
Press Enter.
When you are connected to the ISDN 7500B Data Module in the pool, a
message similar to the following appears:
Connected
Call Status:
Type H for help:
3. Using the data terminal keyboard, dial the number for the digital data
station you are calling. (This is the second stage of dialing.)
When calling an inside digital data station, type a "d" followed by a space
and the extension number of the digital data station you are calling and
press Enter.
Use the data terminal keyboard to enter modem commands and dial the
number.
For example, to call a digital data station at extension 725:
Type d 725.
Press Enter.
To call an outside digital data station, dial the outside telephone number
including the dial-out code (if required) to select the outside line/trunk. You
can use a Speed Dial code instead of dialing the telephone number.
Note: Calls to outside digital data stations must be made using ISDN-PRI
lines/trunks. To enter an account code, you must dial #82, the account code,
and # before you dial the dial-out code and telephone number.
4. Use the instructions supplied with your modem or data communications
software to send data, receive data, and disconnect the call.
Your modem can automatically answer incoming data calls, such as electronic
mail messages, if your computer or data terminal is on and you have set your
modem for automatic answer.
If you have an analog multiline telephone, see the "Auto Answer All" instructions
in this chapter.
Idle
