System Programming
What You See
Extensions:
Make a selection
LinesTrunks RestrctCopy
Line Copy
Dial OutCd BIS/HFAI
Restriction Call Pickup
VoiceSignl>
Exit
Assign Lines/Trunks:
Enter extension
Backspace
Enter
Exit
Assign Lines/Trunks:
Enter extension
xxxx
Backspace
Exit Enter
xxxx = extension number entered in step 3
Extension xxxx:
Assign lines/trunks
Lines 01-20 Entry node
Lines 21-40
Lines 41-60
Lines 61-80
Exit
xxxx = extension number entered in step 3
What You Do...
2. Select Assign Lines and Trunks
3. Identify data station you want to
program in any one of the following
ways:
Extension no.
Slot and port no.
Logical lD no.
DSS
Digits appear on screen as you dial or type. lf
you make an error, select Backspace or press
F4 and retype.
4.
Save your entry
If you get the Station Busy message, wait for an
idle condition, or exit system programming and
try again later.
5. Select the specific lines or trunks
associated with the 20 line buttons on
the console or SPM screen
To select lines or trunks with logical
IDs 1-20
To select lines or trunks with logical
IDs 21-40
To select lines or trunks with logical
IDs 41-60
To select lines or trunks with logical
IDs 61-80
Console PC
F1
LinesTrunks
Dial: Type:
[nnnn] [nnnn]
[sspp]
[sspp]
# [nnn]
# [nnn]
Press DSS
button for
extension no.
F 1 0
E n t e r
F1
Lines 01-20
F2
Lines 21-40
F3
Lines 41-60
F4
Lines 61-80
Programming Instructions
4-5
