24xx
Note: For maximum print quality, adjust the head gap on both the
left and right sides of the printer to within +/- 0.01mm. If the gap
value exceeds the specified range, return to step 4 and re-adjust
both left and right gap adjust bushings.
11. After confirming the head gap is within the specified range for all
(left, right and center) printhead positions, apply Lock Tite on
both bushings.

Bidirectional Print Adjustment

After replacing any mechanical part which affects the operation of
the logic board or the carrier, perform the following procedure to
adjust the bidirectional print. This adjustment cannot be completed if
the printer runs out of paper, so be sure to use continuous forms.
1. Through the Setup Menu, be sure the Default Macro is set to
Disabled.
2. Turn the printer off.
3. Open the operator panel cover to access layer two.
4. Press and hold the Pitch key, while turning the printer on.
– The draft alignment bars print.
– The current value is the number printed below the bars.
5. To set Draft, select the best alignment from the alignment bars
in rows 01 - 11.
6. Press Micro
number, or keep the current value. After selecting, the printer
prints a single row showing the current alignment setting.
7. Press Set TOF to save the selection.
– The printer automatically prints the alignment bars for NLQ.
– The current value is the number printed below the bars.
8. To set NLQ, select the best alignment from the alignment bars
in rows 01 - 11. The current value is the number printed below
the bar.
9. Press Micro
number, or keep the current value. After selecting, the printer
prints a single row showing the current alignment setting.
10. Press Set TOF to save the selection.
11. Close the operator panel cover. The printer returns to Ready.
4-4
Service Manual
or Micro to select the best alignment by
or Micro to select the best alignment by
