24xx
Printhead Impedance Tables
2480, 2490 - Approximately 5 ohms
2481, 2491 - Approximately 8 to 16 ohms
Dot
Connector
1
CN300-1 & CN301-9
2
CN300-1 & CN301-11
3
CN300-1 & CN301-7
4
CN300-1 & CN301-13
5
CN300-1 & CN301-5
6
CN300-1 & CN301-15
7
CN300-1 & CN301-3
8
CN300-1 & CN301-17
9
CN300-1 & CN301-1
10
CN300-1 & CN301-18
11
CN300-1 & CN301-2
12
CN300-1 & CN301-16
2-30
Service Manual
Dot
Connector
1
CN400-13 & CN400-4
2
CN400-9 & CN400-6
3
CN400-15 & CN400-18
4
CN400-1 & CN400-7
5
CN400-17 & CN400-20
6
CN400-5 & CN400-2
7
CN400-19 & CN400-16
8
CN400-8 & CN400-3
9
CN400-10 & CN400- 14
Dot
Connector
13
CN300-1 & CN300-9
14
CN300-1 & CN300-11
15
CN300-1 & CN300-2
16
CN300-1 & CN300-16
17
CN300-1 & CN301-4
18
CN300-1 & CN300-14
19
CN300-1 & CN301-6
20
CN300-1 & CN300-12
21
CN300-1 & CN300-4
22
CN300-1 & CN300-10
23
CN300-1 & CN300-6
24
CN300-1 & CN300-8
