Logic Board - Printhead (24w)

Connector
CN300
Pin #
Signal
1
+40 V dc
2
R15
3
+40 V dc
4
R21
5
+40 V dc
6
R23
7
+40 V dc
8
L24
9
R13
10
L22
11
L14
12
L20
13
+40 V dc
14
L18
15
+40 V dc
16
L16
17
+40 V dc
Connector Locations
5-13
