Lexmark Forms Printer 2400 Service Manual page 26

24xx
Symptom
Load/Unload
does not function
when the push
tractor is installed.
Form feed length is
not correct.
Load/Unload
functions with cut
sheets in use.
Continuous forms
feed, but cut sheets
fail to load.
Load/Unload
functions when the
pull tractor is
installed.
With Paper Out
blinking, FormFeed
does not operate
until paper is located
at first print line.
2-8
Service Manual
Action
Be sure the paper select lever is in the correct
position.
Go to "Paper Select Sensor Service Check" on
page 2-25.
Be sure the paper select lever is in the cut sheet
position.
Verify that continuous forms have been parked
using the Load/Unload button.
Be sure Auto Cut Sheet is enabled in the Setup
Mode.
Go to "Paper Select Sensor Service Check" on
page 2-25.
Be sure the paper select lever is in the tractor
position.
Go to "Pull Tractor Sensor Service Check" on
page 2-31.
