Lexmark Forms Printer 2400 Service Manual page 123

2400 series forms printer
Hide thumbs Also See for Forms Printer 2400:
Table of Contents

Advertisement

24xx
Logic Board - Printhead (24w)
Connector
CN301
Pin #
Signal
1
R9
2
R11
3
R7
4
R17
5
R5
6
R19
7
R3
8
HDTHERMO
9
R1
10
+5 V dc
11
L2
12
+40 V dc
13
L4
14
+40 V dc
15
L6
16
L12
17
L8
18
L10
Connector Locations
