Logic Board - Parallel Interface Cable (9w & 24w)
Connector
CN11
Pin #
Signal
1
-Strobe
2
Data 0
3
Data 1
4
Data 2
5
Data 3
6
Data 4
7
Data 5
8
Data 6
9
Data 7
10
-Acknlg
11
Busy
12
PE
13
Select
14
-AUTFED
15
NC
16
Signal Gnd
17
Chassis Gnd
18
+5 V dc
Pin #
Signal
19
Signal Gnd
20
Signal Gnd
21
Signal Gnd
22
Signal Gnd
23
Signal Gnd
24
Signal Gnd
25
Signal Gnd
26
Signal Gnd
27
Signal Gnd
28
Signal Gnd
29
Signal Gnd
30
Signal Gnd
31
-INIT
32
-ERROR
33
Signal Gnd
34
NC
35
+5 V dc
36
-SELIN
Connector Locations
