24xx
Print Handling Removals
Platen Removal
1. Remove the top cover. Go to
page
4-8.
2. Remove the two platen screws [A] from each end of the platen.
3. Remove the platen from the paper tray.
4. Perform the Printhead-to-Platen Gap adjustment. Go to
"Printhead-to-Platen Gap Adjustment" on page
4-26
Service Manual
"Covers, Top Removal" on
4-2.
