7. Parts Catalog

How To Use This Parts Catalog

SIMILAR ASSEMBLIES: If two assemblies contain a majority of
identical parts, they are shown on the same list. Common parts are
shown by one index number. Parts peculiar to one or the other of the
assemblies are listed separately and identified by description.
NS: (Not Shown) in the Asm-Index column indicates that the part is
procurable but is not pictured in the illustration.
Note: Graphic artwork depicting FRU assemblies is designed using
the 2480-100 (9-wire) model, as reference. Some of the artwork may
not be completely representative of all models. For example, the 24-
wire models are not depicted with two printhead cables and there is
no artwork depicting the extended carriage models 2481 or 2491.
7-1
Parts Catalog
