Logic Board - Operator Panel (9w & 24w)
Connector
CN13
Logic Board
Connector
CN1
Operator Panel
Pin #
Signal
1
+5 V dc
2
SLATCH
3
+5 V dc
4
TXD
5
Signal Gnd
6
RXD
7
Signal Gnd
8
SCLK
9
SG
Pin #
Signal
1
+5 V dc
2
SLATCH
3
+5 V dc
4
TXD
5
Signal Gnd
6
RXD
7
Signal Gnd
8
SCLK
9
SG
