Chapter 58 Troubleshooting Your Fabric
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m

Clearing Configured fcanalyzer Information

Use the clear fcanalyzer command to clear the entire list of configured hosts. Note that the existing
connections are not terminated.

Displaying Configured Hosts

Use the show fcanalyzer command to display the list of hosts configured for a remote capture. See
Example
Example 58-1 Displays Configured Hosts
switch# show fcanalyzer
PassiveClient = 10.21.0.3
PassiveClient = 10.21.0.3
ActiveClient = 10.21.0.3, DEFAULT
The DEFAULT in the ActiveClient line indicates that the default port is used.
Note

Displaying Captured Frames

You can selectively view captured frames by using the display filters feature. For example, instead of
viewing all the frames from a capture, you may only want to view Exchange Link Protocol (ELP) request
frames. This feature only limits the captured view—it does not affect the captured or the saved frames.
Procedures to specify, use, and save display filters are already documented in the Ethereal web site
(http://www.ethereal.com). Some examples of how you can use this feature are as follows:
•
•
•
OL-16184-01, Cisco MDS SAN-OS Release 3.x
ethereal -i rpcap://<ipaddress|hostname>[:<port>]/<interface>
For example:
ethereal -i rpcap://172.22.1.1/eth2
or
ethereal -i rpcap://customer-switch.customer.com/eth2
For example, in a Windows 2000 setup, click Start on your desktop and select Run. In the
Note
resulting Run window, type the required command line option in the Open field.
58-1.
To view all packets in a specified VSAN, use this expression:
mdshdr.vsan == 2
To view all SW_ILS frames, use this expression:
fcswils
To view class F frames, use this expression:
mdshdr.sof == SOFf
Cisco MDS 9000 Family CLI Configuration Guide
Cisco Fabric Analyzer
58-9
