troubleshooting your hp visualization center sv6
troubleshooting tree
• Boot each Workstation and configure the network files (for example,
use setparms ip_address).
• Power up the Digi EtherLite serial port switch and configure it with
an IP address and automatically generated node device files
(/usr/sts/Install).
• Power up the Gigabit LAN switch. Default Gigabit hostnames and IP
addresses were pre-configured.
• Reboot machines when all are configured (master will boot in
/etc/init3).
• Connect stereoscopic equipment to the Compositor controller card -
enable stereo mode as documented in the sv6 Installation/User
Guide.
• Run cable and configuration verification test:
/opt/graphics/common/bin/setpipes -test

3. Problems Powering Up

• See the sv6 Site Prep Guide to verify:
Your PDU must have the appropriate voltage and connector type
for your site.
Power cords must have the proper connectors for your PDU.
You must have the proper power and cooling facilities.
J6000 doesn't power on
• If the digital output on the front of the machine is on, but the boot
doesn't complete, see the "Network Attachment Problems" section.
• Tighten thumb screws on the Workstation. (On J6000s, it is under the
face plate on the front).
• Check the back of the Workstation to see if the fan is unobstructed
and turning.
• Swap with a known good power outlet (i.e. if monitor is getting power,
plug its cord into the J6000).
• Look at the Workstation's digital display.
Is the green backlight on with a little heart blinking on and off?
18 Chapter 1
