Installing the Rubber Feet

To install the rubber feet:
1. Lay the thin client on its right side.
2. Remove the feet from their backing.
3. Press each foot down securely onto a corner of the left side of the thin client.
Figure 1-6

Installing the Stand

If the thin client will be installed in an vertical orientation and it will not be mounted, the stand should
be installed for stability.
To install the stand:
1. Turn unit upside down.
2. Locate the slots on the bottom of the unit into which the tabs on the stand fit.
3. Insert the tabs into the slots (1), and then slide the stand about 1.26 cm (1/2 inch) toward the
back of the unit until it locks into place (2).
Figure 1-7
Installing the rubber feet
Installing the stand
